tPADS
transPortable Asset Decontamination System
The AeroClave™ transPortable Asset Decontamination System (tPADS) is a decontamination chamber built into a shipping container that utilizes our automated aerosolized decontamination technology.
Product details
The AeroClave™ transPortable Asset Decontamination System (tPADS) is an environmentally friendly, computer controlled chamber that utilizes dual decontamination technologies. The tPADS allows assets of many types and sizes to be treated quickly, safely, and effectively in a matter of minutes.
Configuration options include fold-down shelves, fold-away chairs and tables, stretcher supports, various gear hangers and more. The tPADS is designed to use our proprietary aerosolized fogging decontamination technology.
Rugged Design
The standard tPADS chamber is contained in a 20′ ISO shipping container, allowing it to be easily transported via aircraft, rail, ship, or truck, but can be custom designed to be integrated into any type of enclosure or structure.
Computer Controlled
The tPADS system is controlled by an easy-to-use computer controller and requires minimal training. The push of a single button controls the entire process from start to finish.
Chemical Decon Technology
The tPADS uses proprietary chemical decon technology.
Configuration Options
The tPADS chamber is flexible enough to be configured to decontaminate virtually any asset.
Fold-Down Shelves
Ramps
Gear Hangers
Stretcher Supports
tPADS Specifications
Configuration
| Total Weight: | 9,000 lbs. |
|---|---|
| Exterior dimensions: | 20′ L x 8′ W x 8′ H |
| Interior dimensions: | 16′ 8″ L x 7′ 3″ W x 7′ 7″ H |
| Total decontamination surface area of 1172 cu ft (33 cu M) |
Configuration Options
| Fold-down shelves |
|---|
| Fold-away chairs and tables |
| Stretcher supports |
| Gear hangers |
| Loading Ramps |
Controls
| Complete computer hardware with an integrated touchscreen controller |
|---|
| Intuitive software monitor and control system |
| Automated control of all decontamination functions including pre-conditioning, injection, and recovery phases |
Power
| 240 VAC single or three phase/ 480 VAC three phase |
|---|
Additional Benefits
- Fully Transportable
- Rapid Cycle Time
- Broad spectrum pathogen kill
- Low Cost of Operation
- Environmentally Friendly
- Safe for Sensitive Equipment
